Name: BluePrint Engines GM 327 C.I.D. 350 HP Fully Dressed Long Block Crate Engines BP327CTCV - electricalmarinesolutions.pl
Price: 6445.00 EUR
Availability: InStock

BluePrint Engines GM 327 C.I.D. 350 HP Fully Dressed Long Block Crate Engines BP327CTCV

€6,445.00

327CI NEW BLOCK LOW PROFILE DELUXE DRESSED CARBURETED, TACH DRIVE DISTRIBUTOR

Overview

Brand: BluePrint Engines

Manufacturer’s Part Number: BP327CTCV

Part Type: Crate Engines

Product Line: BluePrint Engines GM 327 C.I.D. 350 HP Fully Dressed Long Block Crate Engines

Summit Racing Part Number: MLL-BP327CTCV

UPC: 00887753908216

Crate Engine Family: Chevy Small Block

Actual Engine Displacement: 5.3L/327

Crate Engine Cylinder Head Material: Aluminum

Advertised Compression Ratio: 9.45:1

Assembled: Yes

Engine Balance: Internal/External

Cam Style: Hydraulic roller, OE roller

Rear Main Seal Style: 1-piece

Intake Manifold Included: Yes

Intake Manifold Style: Carbureted

Cylinder Heads Included: Yes

Carburetor Included: Yes

Throttle Body Included: No

Distributor Included: Yes

Oil Pan Included: Yes

Valve Covers Included: Yes

Timing Cover Included: Yes

Water Pump Included: No

Harmonic Balancer Included: Yes

Flexplate Included: No

Flywheel Included: No

Air Cleaner Included: Yes

Spark Plugs Included: Yes

Spark Plug Wires Included: Yes

Computer Included: No

Wiring Harness Included: No

Supercharger Included: No

Remanufactured: No

Quantity: Sold individually.

Notes: Engine has 4-bolt mains. Includes tachometer drive distributor..

Special Attention: Includes a 670 cfm carburetor with electric choke.

BluePrint Engines GM 327 C.I.D. 350 HP Fully Dressed Long Block Crate Engines

BluePrint Engines GM 327 c.i.d. 350 hp fully dressed long block crate engines are available with a Holley Sniper EFI system or a 670 cfm carburetor with electric choke. Both versions are also offered with or without a polished front pulley.

BASIC ENGINE SPECS:

* HP and torque: 350 hp / 350 lbs.-ft.
* Compression ratio: 9.4:1
* Aluminum heads
* Hydraulic roller cam
* Forged crank
* Hypereutectic pistons

BLOCK:

* NEW BluePrint cast iron block
* 4-bolt main
* 4.000 in. bore
* 1-Piece rear main seal
* Mech fuel pump provision: Yes
* Passenger side dipstick
* Drilled and tapped for clutch linkage

ROTATING ASSEMBLY:

* New BluePrint forged crankshaft
* 3.250 in. stroke
* Forged 5.700 in. connecting rods with 150,000 psi bolts
* Hypereutectic pistons
* Internal Front / External Rear

CYLINDER HEADS:

* BluePrint aluminum cylinder heads
* 64cc chamber
* 2.02 in. intake/1.60 in. exhaust valves
* 195cc intake/75cc exhaust runners

CAM SPECS:

* Cam Type: Roller
* .495 Intake .502 Exhaust
* 220 Intake / 224 Exhaust duration
* At .050, 114 degree lobe separation angle

IGNITION TIMING:

* 32-34 degrees total at 3500 rpm

ALSO INCLUDES:

* Premium Vintage valve covers
* Premium Vintage air cleaner
* 6.75 in. harmonic balancer
* Spark plugs
* Under header spark plug wires (perfect for Rams Horn exhaust manifolds)
* Oil pan
* Timing cover
* Aluminum Intake manifold
* Small cap ready-to-run distributor equipped with Tach Drive and coil
* Dyno tested and shipped with results
* Warranty: 30 month / 50,000 mile
* Front accessory drive with water pump, A/C compressor, alternator, and power steering pump

NOTES:

* Not for use in pollution-controlled vehicles.
* The front accessory drive on this engine fits many vehicles, however it is the customer responsibility to accurately measure and confirm fitment. Note this is a low-profile design, but things such as power steering hoses, alternator wiring, and additional fittings/fabrication may be required on some vehicles.
